Are made of iron steel, protected against corrosion, by painting process or phosphating anticorrosion procedure and final hot-dip galvanization. They purify the water from impurities, allowing the usage of same water for irrigation purposes. The choice of model is based on the amount of water applied, water source, pressure characteristics. Filtering capacity depends on the selected model. Compatible with fertigation.
Showing all 12 results
Wire Lock closing system
FAST OPENING LID FOR IRRIGATION FILTERS The lid is made of plastic, lightweight, resistant to light, chemical agents, fertilizers and totally recyclable. The operations of opening and closing the cover require a minimum effort but at the same time offer maximum safety by making impossible the opening under pressure Working pressure PN 16 bar certified…
Automatic back-flush FILTROQUARZ 2C
For automating backwashing features, wide water flow hydrovalves and programmable control units for time and pressure should be used. Backwashing operations should be performed in order to maintain the pressure differential between the inlet and outlet of the filter within a 1.5 bar maximum value.
Fertilizer
The Fertilizer is a very simple and efficient system for the injection of fertilizers. It is applied in sprinkler irrigation, drip and micro-irrigation systems. The Fertilizer allows the use of water-soluble and liquid fertilizers. It can work with a minimum pressure difference (0.5 bar) and up to a maximum pressure of 6 bar. Thanks to the flowmeter you can adjust the amount of liquid entered into the plant from 1 to 25 liters per minute. Available in vertical and horizontal.
FILTROQUARZ 1C
The quartzite filter FILTROQUARZ 1 is used for the first water filtration from rivers, canals, dams and lakes. It makes sure that very small particles such as algae, organic materials and microorganisms that cause severe blockages in drip irrigation systems, are intercepted. All filters are hot galvanized steel made and they are equipped with polypropylene drainage diffusers with 0.5 mm slits. For a proper filtration system it is recommended to install at least 2 quartzite filters.
Manual back-flush FILTROQUARZ 2C
The FILTROQUARZ2 is used for first filtering of waters coming from rivers, canals, dams, lakes and allows trapping very small particles like algae, organic matters and micro-organisms causing serious clogging troubles to microirrigation systems. All Giunti double-chamber quartzite filters are made of hot galvanised steel and complete with draining outlets of polypropylene with openings of…
FILTROQUARZ 1C with automatic washing battery
For a proper filtration system it is recommended to install at least 2 quartzite filters. For automating backwashing features, wide water flow hydrovalves and programmable control units for time and pressure should be used. Backwashing operations should be performed in order to maintain the pressure differential between the inlet and outlet of the filter within a 1.5 bar maximum value.
FILTROQUARZ 2C
The double chamber quartzite filter is used for the first water filtration from rivers, canals, dams and lakes. It makes sure that very small particles such as algae, organic materials and microorganisms that cause severe blockages in drip irrigation systems, are intercepted. All filters are hot galvanized steel made and they are equipped with polypropylene drainage diffusers with 0.5 mm slits.Into the filters there are 4 inspection openings to introduce and remove easily the quartzite.
Hydrocyclone sand separator
The hydrocyclone is a sand and inorganic particles separator and works as a centrifugal. Its particular structure creates a vortex at the entrance of the water that allows the separation of heavier particles due to the centrifugal force. The separation takes place continuously with always constant working pressure and without moving parts. The solid particles separated from the water are deposited in an appropriate collection tank equipped with a comfortable opening to be easily emptied.
